| dn | size | a | b | c | d | e | l | h | i |
| dn15 | 3/4" | 108 | 66 | 18 | 15 | 65 | 76.5/85.5 | 25 | 10 |
| dn20 | 118 | 75 | 19 | 22 | 65 | 76.5/85.5 | 25 | 10 | |
| dn25 | 1" | 127 | 82 | 25 | 28 | 89 | 93/103.5 | 28 | 10 |
| dn32 | 1 1/4" | 146 | 98.5 | 31 | 34 | 109 | 107/124.5 | 36 | 11 |
| dn40 | 1 1/2" | 160 | 105.5 | 37 | 40 | 109 | 107/124.5 | 39 | 14 |
| dn50 | 2" | 190 | 123 | 49 | 52 | 139 | 129/151.5 | 46.5 | 12 |
| dn65 | 2 1/2" | 216 | 129.5 | 67 | 70 | 200 | 140/168 | 55 | 10 |
| 3a | size | 3/4" | 1" | 1 1/4" | 1 1/2" | 2" | 2 1/2" |
| c | 15.75 | 22.1 | 28.5 | 34.8 | 47.5 | 60.2 | |
| d | 19.05 | 25.4 | 31.8 | 38.1 | 50.8 | 63.5 |
| sms/iso | size | 19 | 25 | 32 | 38 | 51 | 63 |
| c | 16.05 | 22.4 | 28.8 | 35.1 | 47.8 | 59.5 | |
| d | 19.05 | 25.4 | 31.8 | 38.1 | 50.8 | 63.5 |
