| dn | size | a | b | h |
| dn6 | 1/4" | 72.0 | 34 | 74.5/79.5 |
| dn8 | 3/5" | 72.0 | 34 | 74.5/79.5 |
| dn10 | 1/2" | 72.0 | 34 | 74.5/79.5 |
| dn15 | 3/4" | 108.0 | 34 | 90.5/99.5 |
| dn20 | 118.0 | 50.5 | 111.5/122 | |
| dn25 | 1" | 127.0 | 50.5 | 111.5/122 |
| dn32 | 1 1/4" | 146.0 | 50.5 | 131.0/148.5 |
| dn40 | 1 1/2" | 160.0 | 50.5 | 131.0/148.5 |
| dn50 | 2" | 190.0 | 64 | 167/190 |
| dn65 | 2 1/2" | 216.0 | 91 | 199/228 |
| 3a | size | 1/4" | 3/8" | 1/2" | 3/4" | 1" | 1 1/4" | 1 1/2" | 2" | 2 1/2" |
| b | 25.2 | 25.2 | 25.2 | 25.2 | 50.5 | 50.5 | 50.5 | 64 | 77.5 |
| sms/iso | size | 6.35 | 9.53 | 12.7 | 19 | 25 | 32 | 38 | 51 | 63 |
| b | 25.2 | 25.2 | 25.2 | 25.2 | 50.5 | 50.5 | 50.5 | 64 | 77.5 |
