| dn | size | a | s | ls | h | d | t |
| dn10 | 1/2" | 90 | 6 | 16 | 76.5/85.5 | 12 | 1.5 |
| dn15 | 3/4" | 90 | 6 | 16 | 76.5/85.5 | 18 | 1.5 |
| dn20 | 90 | 6 | 16 | 93/103.5 | 22 | 1.5 | |
| dn25 | 1" | 120 | 6 | 20 | 93/103.5 | 28 | 1.5 |
| dn32 | 1 1/4" | 160 | 6 | 20 | 107/124.5 | 34 | 1.5 |
| dn40 | 1 1/2" | 160 | 6 | 20 | 107/124.5 | 40 | 1.5 |
| dn50 | 2" | 200 | 6 | 30 | 129/151.5 | 52 | 1.5 |
| 3a | size | 1/2" | 3/4" | 1" | 1 1/4" | 1 1/2" | 2" |
| d | 12.7 | 19.05 | 25.4 | 31.8 | 38.1 | 50.8 | |
| t | 1.65 | 1.65 | 1.65 | 1.65 | 1.65 | 1.65 |
| sms/iso | size | 12.7 | 19 | 25 | 32 | 38 | 51 |
| d | 12.7 | 19.05 | 25.4 | 31.8 | 38.1 | 50.8 | |
| t | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
