| size | a | i | b | r | c | d | e | t | f | h | |
| dn20 | 146 | 90 | 171 | 40 | 81 | 93/103.5 | 22 | 1.5 | 50.5 | 18 | |
| dn25 | 179 | 100 | 201.5 | 50 | 101.5 | 93/103.5 | 28 | 1.5 | 50.5 | 23 | |
| dn32 | 214 | 105 | 228 | 55 | 123 | 107/124.5 | 34 | 1.5 | 50.5 | 28.5 | |
| dn40 | 224 | 110 | 242 | 60 | 132 | 107/124.5 | 40 | 1.5 | 50.5 | 30 | |
| dn50 | 261 | 120 | 277 | 70 | 157 | 129/151.5 | 52 | 1.5 | 64 | 38 |
| sms/iso | size | a | i | b | r | c | d | e | t | f | h |
| 19 | 3/4" | 123 | 80 | 161 | 28.5 | 81 | 93/103.5 | 19.05 | 1.5 | 25.2 | 18 |
| 25 | 1" | 146 | 90 | 191.5 | 33.5 | 101.5 | 93/103.5 | 25.4 | 1.5 | 50.5 | 23 |
| 32 | 1.25" | 180 | 90 | 213 | 38 | 123 | 107/124.5 | 31.8 | 1.5 | 50.5 | 28.5 |
| 38 | 1.5" | 201 | 100 | 232 | 48.5 | 132 | 107/124.5 | 38.1 | 1.5 | 50.5 | 30 |
| 51 | 2" | 242 | 110 | 267 | 60.5 | 157 | 129/151.5 | 50.8 | 1.5 | 64 | 38 |
