| dn | size | a | b | c | port | d | e | l |
| dn20 | 3/4" | 129 | 19 | 50.5 | 15 | 64.5 | 55 | 160 |
| dn25 | 1" | 135 | 25 | 50.5 | 20 | 67.5 | 65 | 200 |
| dn32 | 1 1/4" | 149 | 31 | 50.5 | 25 | 74.5 | 71.5 | 200 |
| dn40 | 1 1/2" | 157 | 37 | 50.5 | 32 | 78.5 | 78 | 200 |
| dn50 | 2" | 182 | 49 | 64.0 | 38 | 91 | 93.6 | 200 |
| 3a | size | 3/4" | 1" | 1 1/4" | 1 1/2" | 2" |
| b | 15.75 | 22.1 | 28.5 | 34.8 | 47.5 |
| sms/iso | size | 19 | 25 | 32 | 38 | 51 |
| b | 16.05 | 22.4 | 28.8 | 35.1 | 47.8 |
