| dn | size | a | b | c | g | h | h2 | l | l2 | iso5211 | s | n.m |
| dn15 | 1/2" | 93 | 34 | 15 | 40.3 | 71 | 129.3 | 130 | 140 | f03 pcd36 6x4 f04 pcd42 6x4 | 9 | 5.5 |
| dn20 | 3/4" | 103.5 | 50.5 | 19 | 42.3 | 73 | 131.3 | 130 | 140 | f03 pcd36 6x4 f04 pcd42 6x4 | 9 | 5.5 |
| dn25 | 1" | 110 | 50.5 | 25 | 53.4 | 91.6 | 142.4 | 165 | 140 | f04 pcd42 6x4 f05 pcd50 7x4 | 11 | 11.8 |
| dn32 | 1 1/4" | 120 | 50.5 | 31 | 58.4 | 96.6 | 147.4 | 165 | 140 | f04 pcd42 6x4 f05 pcd50 7x4 | 11 | 14.2 |
| dn40 | 1 1/2" | 129 | 50.5 | 37 | 70.8 | 104 | 175.8 | 190 | 159 | f05 pcd50 7x4 f07 pcd70 9x4 | 14 | 19.0 |
| dn50 | 2" | 145 | 64 | 49 | 77.8 | 110 | 182.8 | 190 | 159 | f05 pcd50 7x4 f07 pcd70 9x4 | 14 | 23.7 |
| 3a | size | 1/2" | 3/4 | 1" | 1 1/4" | 1 1/2" | 2" |
| b | 25.2 | 25.2 | 50.5 | 50.5 | 50.5 | 50.5 | |
| c | 9.4 | 15.75 | 22.1 | 28.5 | 34.8 | 47.5 |
| sms/iso | size | 12.7 | 19 | 25 | 32 | 38 | 51 |
| b | 25.2 | 25.2 | 50.5 | 50.5 | 50.5 | 50.5 | |
| c | 9.7 | 16.05 | 22.4 | 28.8 | 35.1 | 47.8 |
