| din | 3a | sms | iso | h | a | b |
dn40 g l rd65x1/6 22.0 | 1 1/2" g1 l 50.65x1/8 tacme 18.3 | 38 g l rd60x1/6 20.0 | φ38 g l 50.6x1/8 tacme 21.5 | 485.0 | 68.0 | 62.0 |
dn50 g l rd78x1/6 22.0 | 2" g l 64.17x1/8 tacme 19.1 | 51 g l rd70x1/6 21.0 | φ51 g l 60.2x1/8 tacme 21.5 | 528.0 | 68.0 | 62.0 |
2 1/2" g l 77.67x1/8 tacme 22.2 | 63 g l rd85x1/6 22.0 | φ63 g l 77.7x1/8 tacme 21.5 | 539.0 | 84.5 | 81.3 | |
dn65 g l rd95x1/6 24.0 | 3" g l 91.19x1/8 tacme 23.1 | 76 g l rd98x1/6 24.0 | φ76 g l 91.2x1/8 tacme 21.5 | 585.0 | 93.6 | 93.5 |
dn80 g l rd110x1/4 28.0 | 596.0 | 118.5 | 115.0 | |||
dn100 g l rd130x1/4 28.0 | 4" g l 119.25x1/6 tacme 26.2 | 102 g rd125x1/4 | φ102 g l 118.4x1/8 tacme 21.5 | 623.0 | 118.5 | 115. |
