dn | size | a | d | d1 | d2 | d3 | d4 | h | l | l1 |
dn15 | 3/4" | 120 | 95 | 65 | 40 | 15 | 4-φ14 | 137 | 180 | 64 |
dn20 | 130 | 105 | 75 | 50 | 19 | 4-φ14 | 145 | 185 | 64 | |
dn25 | 1" | 140 | 115 | 85 | 60 | 25 | 4-φ14 | 173 | 210 | 80 |
dn32 | 1 1/4" | 150 | 135 | 100 | 70 | 31 | 4-φ18 | 210 | 240 | 80 |
dn40 | 1 1/2" | 180 | 145 | 110 | 80 | 37 | 4-φ18 | 260 | 245 | 80 |
dn50 | 2" | 195 | 160 | 125 | 92 | 49 | 4-φ18 | 300 | 295 | 100 |
dn65 | 2 1/2" | 230 | 185 | 145 | 115 | 66 | 4-φ18 | 315 | 320 | 126 |
dn80 | 3" | 250 | 195 | 160 | 130 | 81 | 8-φ18 | 330 | 330 | 126 |
dn100 | 4" | 280 | 215 | 180 | 150 | 100 | 8-φ18 | 350 | 360 | 156 |
| 3a | size | 3/4" | 1" | 1 1/4" | 1 1/2" | 2" | 2 1/2" | 3" | 4" |
| d3 | 15.75 | 22.1 | 28.5 | 34.8 | 47.5 | 60.2 | 72.9 | 97.4 |
| sms/iso | size | 19 | 25 | 32 | 38 | 51 | 63 | 76 | 102 |
| d3 | 16.05 | 22.4 | 28.8 | 35.1 | 47.8 | 59.5 | 72.2 | 97.6 |
