| din | size | l1 | k | d | r |
| dn15 | 53.0 | 34.0 | 18.0 | 35.0 | |
| dn20 | 58.0 | 34.0 | 22.0 | 40.0 | |
| dn25 | 71.0 | 50.5 | 28.0 | 50.0 | |
| dn32 | 76.0 | 50.5 | 34.0 | 55.0 | |
| dn40 | 81.0 | 50.5 | 40.0 | 60.0 | |
| dn50 | 91.0 | 64.0 | 52.0 | 70.0 | |
| dn65 | 101.0 | 91.0 | 70.0 | 80.0 | |
| dn80 | 111.0 | 106.0 | 85.0 | 90.0 | |
| dn100 | 121.0 | 119.0 | 104.0 | 100.0 |
| 3a | size | l1 | k | d | r |
| 1/2" | 40.5 | 25.2 | 1.7 | 19.05 | |
| 3/4" | 50.0 | 25.2 | 19.05 | 28.5 | |
| 1" | 50.8 | 50.5 | 25.4 | 38.1 | |
| 1 1/4" | 60.4 | 50.5 | 31.8 | 47.7 | |
| 1 1/2" | 69.9 | 50.5 | 38.1 | 57.2 | |
| 2" | 88.9 | 64.0 | 50.8 | 76.2 | |
| 2 1/2" | 108.0 | 77.5 | 63.5 | 95.3 | |
| 3" | 127.0 | 91.0 | 76.2 | 114.3 | |
| 4" | 168.3 | 119.0 | 101.6 | 152.4 |
