| din | size | l1 | d | r | t |
| dn10 | 38.0 | 12.0 | 26.0 | 1.5 | |
| dn15 | 47.0 | 18.0 | 35.0 | 1.5 | |
| dn20 | 52.0 | 22.0 | 40.0 | 1.5 | |
| dn25 | 70.0 | 28.0 | 50.0 | 1.5 | |
| dn32 | 78.0 | 34.0 | 55.0 | 1.5 | |
| dn40 | 85.0 | 40.0 | 60.0 | 1.5 | |
| dn50 | 97.0 | 52.0 | 70.0 | 1.5 | |
| dn65 | 110.0 | 70.0 | 80.0 | 2.0 | |
| dn80 | 118.0 | 85.0 | 90.0 | 2.0 | |
| dn100 | 140.0 | 104.0 | 100.0 | 2.0 |
| 3a | size | l1 | d | r | t |
| 1/2" | 52.4 | 12.7 | 19.05 | 1.65 | |
| 3/4" | 52.4 | 19.05 | 28.5 | 1.65 | |
| 1" | 52.4 | 25.4 | 38.1 | 1.65 | |
| 1 1/4" | 64.0 | 31.8 | 47.7 | 1.65 | |
| 1 1/2" | 74.6 | 38.1 | 57.2 | 1.65 | |
| 2" | 103.2 | 50.8 | 76.2 | 1.65 | |
| 2 1/2" | 131.8 | 63.5 | 95.3 | 1.65 | |
| 3" | 160.3 | 76.2 | 114.3 | 1.65 | |
| 4" | 211.1 | 101.6 | 152.4 | 2.1 |
