| size | l1 | d | d2 | t1 | t2 |
| dn15 dn10 | 35.0 | 18.0 | 12.0 | 1.5 | 1.5 |
| dn20 dn15 | 40.0 | 22.0 | 18.0 | 1.5 | 1.5 |
| dn25 dn15 | 50.0 | 28.0 | 18.0 | 1.5 | 1.5 |
| dn25 dn20 | 50.0 | 28.0 | 22.0 | 1.5 | 1.5 |
| dn32 dn25 | 55.0 | 34.0 | 28.0 | 1.5 | 1.5 |
| dn40 dn25 | 60.0 | 40.0 | 28.0 | 1.5 | 1.5 |
| dn40 dn32 | 60.0 | 40.0 | 34.0 | 1.5 | 1.5 |
| dn50 dn32 | 70.0 | 52.0 | 34.0 | 1.5 | 1.5 |
| dn50 dn40 | 70.0 | 52.0 | 40.0 | 1.5 | 1.5 |
| dn65 dn50 | 80.0 | 70.0 | 52.0 | 1.5 | 1.5 |
| dn80 dn50 | 90.0 | 85.0 | 52.0 | 1.5 | 1.5 |
| dn80 dn65 | 90.0 | 85.0 | 70.0 | 2.0 | 2.0 |
| dn1 00 dn50 | 100.0 | 104.0 | 52.0 | 1.5 | 1.5 |
| dn100 dn65 | 100.0 | 104.0 | 70.0 | 2.0 | 2.0 |
| dn100 dn80 | 100.0 | 104.0 | 85.0 | 2.0 | 2.0 |
| 3a | size | l1 | d | d2 | t1 |
| 3/4" 1/2" | 47.6 | 19.05 | 12.7 | 1.65 | |
| 1" 1/2" | 47.6 | 25.4 | 12.7 | 1.65 | |
| 1" 3/4" | 47.6 | 25.4 | 19.05 | 1.65 | |
| 1 1/4" 1" | 47.7 | 31.8 | 25.4 | 1.65 | |
| 1 1/2" 1" | 57.2 | 38.1 | 25.4 | 1.65 | |
| 1 1/2" 1 1/4" | 57.2 | 38.1 | 31.8 | 1.65 | |
| 2" 1 1/4" | 76.2 | 50.8 | 31.8 | 1.65 | |
| 2" 1 1/2" | 76.2 | 50.8 | 38.1 | 1.65 | |
| 2 1/2" 2" | 76.2 | 63.5 | 50.8 | 1.65 | |
| 3" 2" | 82.6 | 76.2 | 50.8 | 1.65 | |
| 3" 2 1/2" | 82.6 | 76.2 | 63.5 | 1.65 | |
| 4" 2" | 98.4 | 101.6 | 50.8 | 2.1 | |
| 4" 2 1/2" | 98.4 | 101.6 | 63.5 | 2.1 | |
| 4" 3" | 98.4 | 101.6 | 76.2 | 2.1 |
