| size | l1 | d | d2 | t |
| dn20/15 | 11 | 22.0 | 18.0 | 1.5x1.5 |
| dn25/20 | 16.5 | 28.0 | 22.0 | 1.5x1.5 |
| dn32/20 | 33.0 | 34.0 | 22.0 | 1.5x1.5 |
| dn32/25 | 16.5 | 34.0 | 28.0 | 1.5x1.5 |
| dn40/20 | 49.5 | 40.0 | 22.0 | 1.5x1.5 |
| dn40/25 | 33.0 | 40.0 | 28.0 | 1.5x1.5 |
| dn40/32 | 16.5 | 40.0 | 34.0 | 1.5x1.5 |
| dn50/25 | 66 | 52.0 | 28.0 | 1.5x1.5 |
| dn50/32 | 49.5 | 52.0 | 34.0 | 1.5x1.5 |
| dn50/40 | 33 | 52.0 | 40.0 | 1.5x1.5 |
| dn65/25 | 110 | 70.0 | 28.0 | 2.0x1.5 |
| dn65/32 | 93.5 | 70.0 | 34.0 | 2.0x1.5 |
| dn65/40 | 77 | 85.0 | 40.0 | 2.0x1.5 |
| dn65/50 | 44 | 85.0 | 52.0 | 2.0x1.5 |
| dn80/40 | 118.2 | 85.0 | 40.0 | 2.0x1.5 |
| dn80/50 | 85 | 104.0 | 52.0 | 2.0x1.5 |
| dn80/65 | 41.2 | 104.0 | 70.0 | 2.0x1.5 |
| dn100/40 | 112.0 | 104.0 | 40.0 | 2.0x1.5 |
| dn100/50 | 137.5 | 104.0 | 52.0 | 2.0x1.5 |
| dn100/65 | 93.5 | 104.0 | 70.0 | 2.0x1.5 |
| dn100/80 | 58.5 | 104.0 | 85.0 | 2.0x1.5 |
