| size | d | d1 | l | h | t |
| 1/4" | 8 | 6.2 | 12 | 47 | 1.5 |
| 1/2" | 8 | 12.5 | 12 | 47 | 1.5 |
| 3/4" | 19 | 19 | 25 | 47 | 1.5 |
| 1" | 19 | 25.4 | 25 | 47 | 1.5 |
| 1 1/2" | 19 | 38.1 | 25 | 47 | 1.5 |
| 2" | 19 | 50.8 | 25 | 47 | 1.5 |
| 2 1/2" | 19 | 63.5 | 25 | 47 | 2 |
| 3" | 19 | 76.2 | 25 | 47 | 2 |
| 4" | 19 | 101.6 | 28 | 47 | 2 |
| 5" | 19 | 129 | 28 | 47 | 2.5 |
| 6" | 19 | 154 | 28 | 47 | 2.5 |
| 8" | 25 | 204 | 35 | 47 | 3 |
| 10" | 25 | 254 | 35 | 47 | 3 |
| 12" | 25 | 304 | 35 | 47 | 3 |
